Omron Slot-type Photomicrosensor EE-SX674P Through-beam

Omron Fork Sensor EE-SX674P PNP open collector, 5mm Range, EE-SX674P OMRON Photoelectric Micro Sensor, EE-SX674 Slot Sensor

The Omron EE-SX674P is a slot-type photomicrosensor used for precise object detection in automation and industrial applications. It has a built-in light-emitting element and a light-receiving element, enabling it to detect objects that break the infrared light beam passing through its 5 mm slot. The sensor features a selectable light-ON/dark-ON operation mode and a PNP open collector output.

Key specifications

• Sensor type: Slot-type photomicrosensor
• Sensing method: Through-beam
• Sensing distance: 5 mm slot width
• Light source: Infrared LED (940 nm peak wavelength)
• Output type: PNP open collector
• Operating modes: Selectable light-ON / dark-ON
• Supply voltage: 5 to 24 VDC
• Response frequency: 1 kHz min. (average 3 kHz)
• Indicator: Red LED (turns ON when light is interrupted for the standard model)
• Protection: Load short-circuit protection
• Operating temperature: -25 to +55°C
• Housing material: PBT and PC
• Connection: Connector
• Protection rating: IP50

Common applications

The Omron EE-SX674P is well-suited for high-speed, space-constrained settings where precise object detection is required. Common applications include:

• Part detection and counting: In feeders or automated assembly lines.
• Position sensing: In semiconductor manufacturing equipment.
• Label edge detection: For packaging and labeling machinery.
• Miniature component detection: For applications involving small objects.
• General automation: For detecting the presence or absence of objects.
