Omron L-shaped Slot-type Photoelectric Microsensor EE-SX674R

Omron Sensor EE-SX674R Photoelectric 5mm Range PNP Output 5 to 24 VDC

The Omron EE-SX674R is a compact, L-shaped, slot-type photomicrosensor for close-mounting applications. It is designed to detect the presence or absence of an object passing through its 5 mm slot.

Specifications

• Sensor type: Slot-type photomicrosensor
• Sensing method: Through-beam (non-modulated infrared light)
• Sensing distance: 5 mm
• Output type: PNP open collector output
• Output current: 50 mA maximum
• Operating modes: Selectable Light-ON or Dark-ON
• Connection: System connector
• Supply voltage: 5 to 24 VDC (with 10% maximum ripple)
• Current consumption: 12 mA
• Indicator: LED for no incident light
• Housing material: Polybutylene terephthalate (PBT)
• Operating temperature: -25°C to 55°C
• Protection rating: IP50 (dust protection)
• Key features: High durability, resistance to shock and vibration, and easy installation with a connector

Applications

The Omron EE-SX674R is used in a variety of high-density, automated systems for precise object detection.

• Robotic arms
• Packaging machines
• Pick-and-place systems
• Counting objects
• Measuring speed
