Omron Slot-type Photomicrosensor EE-SX675 Through-beam Sensor

EE-SX675 EESX675 Omron Sensor, Omron Photoelectric Sensor EE-SX675

The Omron EE-SX675 is a slot-type photomicrosensor, a type of photoelectric switch used in industrial automation. It operates on a through-beam principle, where an infrared LED light source is on one side of a slot and a phototransistor receiver is on the other. When an object passes through the 5mm wide slot, the light beam is interrupted, causing the sensor to switch output.

Specifications

• Sensing method: Through-beam (transmissive), non-modulated infrared light.
• Shape: T-shaped module with a 10mm slot center.
• Sensing distance: 5 mm slot width.
• Output: NPN open-collector output.
• Output modes: Selectable Light-ON/Dark-ON operation.
• Supply voltage: 5 to 24 VDC.
• Response frequency: 1 kHz maximum.
• Indicator: Bright LED indicator for easy operation monitoring.
• Connection method: Connector-type.
• Housing material: Thermoplastic PBT polymer.
• Operating temperature: -25°C to +55°C.
• IP rating: IP50 (dust protection).
