EE-SX951-R OMRON Sensor

EE-SX951-R OMRON Sensor
Key Specifications & Features

• Form Factor: L-shaped compact housing that can be mounted horizontally or vertically using M3 or M2 screws.
• Sensing Mechanism: Through-beam slot type with a 5 mm slot width and a dependable 6.5 mm slot depth.
• Electrical Output: NPN open collector output with a maximum load capacity of 50 mA.
• Dual Operation Modes: Equipped with 2 integrated outputs allowing both Light-ON and Dark-ON switching actions.
• Supply Voltage: Operates reliably across a wide range of 5 to 24 VDC.
• High-Flexibility Cable: The "-R" variant denotes a specialized robotic/flexible cable (available in lengths like  ) designed to survive constant movement in robotic arms and moving machinery.
• Indicator & Protection: Features a highly visible bright indicator light viewable from multiple directions and built-in load short-circuit protection.
• Ingress Protection: Rated at IP50 for reliable dust shielding.

Common Applications

• Positioning monitoring in moving machine parts and multi-axis Cartesian robots.
• Limit sensing and home-position detection in factory conveyor belts.
• Counting or verifying the presence of fast-moving items or slotted disks (reaches a high response frequency of up to 3 kHz).
