EE-SX972C1 photomicro sensor

EE-SX972C1 photomicro sensor
Key Technical Specifications

• Sensing Type: Through-beam (slotted/fork)
• Shape: T-shaped (slot center at 7 mm)
• Sensing Distance: 5 mm
• Output Configuration: NPN output
• Operating Voltage: 5 to 24 VDC
• Response Time: 0.17 ms
• Housing Material: PBT (Polybutylene Terephthalate)
• Enclosure Rating: IP50

Applications and Use

• Object edge or position detection in automated machinery
• Presence verification on conveyor lines
• Counting and limit-sensing in electronic assembly equipment
