ER3V3.6V TOSHIBA
Key Specifications
- Size: 1/2AA (Approx. \(14.5\text{mm}\) diameter \(\times\ 24.5\text{mm}\) height)
- Voltage: \(3.6\text{V}\) (Nominal)
- Capacity: \(1000\text{mAh}\)
- Weight: \(8.5\text{g}\)
- Operating Temperature: \(-40^{\circ}\text{C}\) to \(+85^{\circ}\text{C}\)
- Shelf Life: Up to 10 years (due to a very low self-discharge rate)
Common Applications
Because of its high energy density and stability, it is widely used for:
- PLC / CNC Memory Backup: Keeps Programmable Logic Controllers and CNC machine data/real-time clocks running during power outages.
- Utility Meters: Acts as the power source for various gas, water, and smart electricity meters.
- Medical & Security Systems: Used in portable diagnostic tools and memory management systems.
Important Handling & Safety Notes
- Non-Rechargeable: Attempting to charge this lithium thionyl chloride cell can result in fire, explosion, or severe burns.
- Connection Options: It is available with flat pin contacts, solder pins, or specific plug connectors (e.g., black 2-pin connectors commonly found in Mitsubishi/Omron PLC setups).
- Soldering: If you are soldering tabs to the battery, keep the soldering temperature below \(270^{\circ}\text{C}\) and do not apply heat for more than 5 seconds.
