ESS-10-SS M4 SMT suction cup

ESS-10-SS M4 SMT suction cup
Key Technical Specifications

• Pad Diameter: 10 mm
• Holding Force: 3.9 N (at nominal operating pressure)
• Material: Silicone
• Connection Type: M4 Male
• Operating Temperature: -30°C to +180°C

How It Works

• Vacuum Generation: A vacuum pump attaches to the M4 port and pulls air out.
• Sealing: The silicone pad conforms to the shape of the object to create an airtight seal.
• Lifting: Atmospheric pressure pushes against the object, letting the machine safely move it. [

AnalogyThink of this suction cup like a tiny, heavy-duty version of a suction-cup hook you use in the bathroom. The machine replaces your hand, and a vacuum pump replaces the act of pressing the cup down.
