Soldering Iron Tip/Bit ETCC flat soldering tip

ETCC Soldering Bit Weller, Soldering Tip ETCC

The Weller ETCC Single Flat Solder Tip is a high-quality, 1/8" flat soldering tip used for general-purpose soldering on Weller soldering stations. It is made of copper with iron and chrome plating for durability and heat transfer.

Product specifications

• Tip shape: Single flat
• Tip width (A): 0.125 inches (3.2 mm)
• Tip diameter (B): 0.032 inches (0.81 mm)
• Tip length (C): 0.625 inches (15.9 mm)
• Temperature range: 350 to 850 °F
• For use with: Weller soldering irons and pencils, including:
  • WE1010, WE1010EDU, WES51, WES50, WESD51, WESD50, LR20, LR21, PES50, PES51, EC1201A, EC1204A, WCC101

• Effective heat transfer: The copper core delivers heat efficiently to the solder point.
• Durability: The iron, nickel, and chrome plating provide a long service life, reducing the need for frequent tip replacements.
• Secure fit: A stainless steel liner in the base of the tip prevents it from seizing to the sensor in the soldering iron.
