Soldering Iron Tip/Bit ETH Chisel Tip

ETH Soldering Bit Weller, Soldering Tip ETH ET Screwdriver Tip .031" x .019" x .625"

The Weller ETH is a screwdriver-style soldering tip from the ET series, specifically designed for various Weller soldering pencils and stations. It is built for electronics work and is compatible with lead-free solder.

Features and specifications

• Tip shape: Screwdriver ( Chisel tip).
• Dimensions: 0.8mm x 0.48mm x 15.9mm (0.031" x 0.019" x 0.625").
• Construction: It has a copper core for efficient heat transfer, with plating layers of iron and chrome to extend its service life.
• Sensor hole: The base of the tip has a stainless steel-lined sensor hole to prevent the tip from seizing to the heating element sensor.
• Temperature range: Operates in a temperature range of 350–850°F (177–454°C).
