EVC141 - Connecting cable with socket

EVC141 - Connecting cable with socket

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

EVC141 - Connecting cable with socket

Application

Special feature Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability
Application Industrial applications / factory automation; Use in machine tools, coolants and lubricants
Free from silicone yes

Electrical data

Operating voltage[V] < 50 AC / < 60 DC
Protection class III
Max. current load total[A] 3

Operating conditions

Ambient temperature[°C] -25...90
Note on ambient temperature
cULus: ...80 °C
Ambient temperature (moving)[°C] -25...90
Note on ambient temperature (moving)
cULus: ...80 °C
Protection IP 65; IP 67; IP 68; IP 69K

Mechanical data

Weight[g] 51.6
Dimensions[mm] 10 x 10 x 31
Moulded-body material TPU
Material nut brass, nickel-plated
Sealing material FKM
Drag chain suitability yes
Drag chain suitability
bending radius for flexible use min. 10 x cable diameter
travel speed max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²
bending cycles > 5 Mio.
torsional strain ± 180 °/m

Remarks

Pack quantity 1 pcs.

Electrical connection

Cable 2 m, PUR, Halogen-free, black, Ø 3.7 mm; 3 x 0.25 mm² (32 x Ø 0.1 mm )

Electrical connection - socket

Connector 1 x M8, straight; coding: A; Contacts: 3, gold-plated; Moulded body: TPU, orange; Locking: brass, nickel-plated; Sealing: FKM; Tightening torque: 0.3...0.5 Nm
