F&C Inductive Proximity Sensor F3N-18DN05-N-R2M

F3N-18DN05-N-R2M Switch Sensor NPN NO, 3-wire, 12-24 V DC, Non-flush, IP67

The F&C F3N-18DN05-N-R2M is a square, non-flush inductive proximity sensor with an NPN normally open (NO) output. Manufactured by F&C Sensors, it detects metallic objects at a distance of up to 5mm.

Specifications

• Manufacturer: F&C Sensors
• Part number: F3N-18DN05-N R2M
• Body style: Square
• Dimensions: 18 x 18 x 36 mm
• Sensing distance: 5 mm
• Mounting: Non-flush
• Output type: NPN Normally Open (NO)
• Response frequency: 600 Hz
• Operating voltage: 12-24 V DC
• Protection rating: IP67
• Protection circuit: Reverse polarity protection, short-circuit protection
• Housing material: PBT and SUS
• Wiring: 3-wire cable (2m)
• Typical detection object: 18 x 18 x 1 mm iron
