Imada FB-100N Mechanical Force Gauge

Imada FB-100N Mechanical Force Gauge Up to 100 N Capacity,
Mechanical Force Gauge FB 100N Analog Push Pull Tester.

The IMADA FB-100N is a robust, analog mechanical force gauge designed for accurate push and pull force measurements up to 100 Newtons. As a mechanical model, it is battery-free and intrinsically safe for use in hazardous environments.

• Capacity: Up to 100 N for both tension (pull) and compression (push) forces.
• Accuracy: ±0.3% of full scale.
• Display: Analog dial with a zero-tare ring to adjust for attachments and measuring positions.
• Operation modes: A selector switch lets you view real-time force changes or capture the peak (maximum) force applied.
• Construction: Ergonomically designed with heavy-duty metal housing for durability and stability.
• Mounting: Can be used handheld or mounted to a test stand for more stable measurements.
• Included accessories: The gauge typically comes as a kit with a hard carrying case and a standard set of measuring attachments, including:
  • Flat head
  • Conical tip
  • Chisel tip
  • Notched head
  • Small hook
  • 3-inch extension shaft

Specification/Additional Details

• Brand : Imada
• Measuring Range : 100N
• Model Name/Number : FB-100N
• Display Type : Analog
• Accuracy : +-0.3%F. S or less
• Capacity : 100N
• Usage/Application : Push-Pull Force Measuring

• Operating environment : 0~+40°C

• Stroke : 10mm
