F&C FC-SPX304 Photoelectric Sensor

F&C 5mm Slot Photoelectric Sensor Switch FC-SPX304 NPN 4-wire 2m Cable 12 to 24V DC, FC-SPX304 Positioning Sensor Infrared 5mm Slot 4-24V DC

Specification/Additional Details

• Sensor Type: Slot or fork-type photoelectric sensor.
• Light Source: 630nm infrared modulated light.
• Detection Method: Through-beam type, where the emitter and receiver are housed in a single U-shaped unit.
• Slot Width: 5mm.
• Detection Object: Can detect objects as small as 1mm in diameter.
• Output: Available in NPN and PNP output signals.
• Operating Voltage: 5-24 VDC.
• Response Time: 0.3ms to 1ms.
• Protection Rating: IP65.
• Material: ABS plastic.
• Dimensions: Approximately 50 x 20 x 15 mm.
