F&C FC-SPX306 Photoelectric Sensor

F&C Photoelectric Switch Sensor FC-SPX306 NPN NO NC 5V to 24V DC Operating Voltage 5mm Sensing Distance 630nm infrared modulated light 0.3ms Max Response Time,
FC-SPX306 Movement Sensor NPN PNP

Specification/Additional Details

• Sensor Type : Through-Beam
• Brand : F&C
• Model : FC-SPX306
• Output : NPN NO NC
• Light Source : 630nm infrared modulated light
• Standard Detection Object : Dia. 1mm opaque object
• Detection Distance : 5mm

• Operating Voltage : 12-24 VDC+/-10%

• Response Time : 0.3ms Max

• Operating Temperature : -10 ~ 50 °C(No icing)

• Protection Degree : IP65
