F&C Photoelectric Switch Sensor FC-SPX306PZ

The FC-SPX306PZ is a slot-type photoelectric switch sensor. It is used in industrial automation for applications like object detection, counting, and positioning. The "PZ" in the model name indicates that it has a PNP (Positive-Negative-Positive) transistor output and both NO (Normally Open) and NC (Normally Closed) switching options.

Specifications

• Sensor type: Slot-type through-beam photoelectric switch
• Brand: F&C Sensing Technology
• Detection distance: 5mm
• Light source: 940nm infrared modulated light, which reduces interference from external light
• Output type: PNP (Positive-Negative-Positive), with both Normally Open (NO) and Normally Closed (NC) outputs available
• Output current: 100mA maximum at 24V DC
• Operating voltage: 5V to 24V DC
• Connection: 4-wire cable
• Protection: Includes power reverse connection protection and short-circuit protection
• Response time: 0.5ms maximum
• Protection degree: IP64
• Applications: Ideal for use on conveyor systems, assembly lines, and in automated systems for precision object detection.
