F&C Slot-type Photoelectric Sensor FC-SPX306Z Positioning Sensor

The FC-SPX306Z is a slot-type photoelectric sensor used in industrial automation for detecting objects. It is manufactured by F&C and is often described as a "U-shaped" sensor due to its fork-like design.

Key specifications

• Sensor type: Slot type.
• Detection method: Through-beam, which involves an emitter and receiver facing each other across a gap.
• Detection distance: 5 mm.
• Output: The output can be either NPN or PNP, with both Normally Open (NO) and Normally Closed (NC) options available.
• Light source: The sensor uses an infrared LED.
• Power supply: 5–24 VDC.
• Protection: Includes protection against short-circuits and reverse polarity.
• Waterproof rating: IP65.
• Connection: Available with a standard cable (2m or 3m).

Common applications

The FC-SPX306Z sensor is commonly used in industrial settings for various automation tasks, including:

• Positioning: Detecting the position of parts on assembly lines.
• Object detection and counting: Counting items as they pass through the slot on a conveyor belt.
• Machine control: Serving as a limit switch for mechanical movements.
• Packaging: Used in punching, cutting, and other packaging machinery.
