F&C Slot-type Photoelectric Sensor FC-SPX307PZ PNP NO NC

Key technical specifications

• Sensing type: Through-beam reflection within a groove or U-shaped slot.
• Output type: PNP (Positive-Negative-Positive) output, with both Normally Open (NO) and Normally Closed (NC) options.
• Sensing distance: 5mm.
• Detection capability: Able to reliably detect opaque objects measuring at least ⌀ 2.0 X 0.8mm.
• Light source: 940nm infrared modulated light, which helps minimize interference from external ambient light.
• Operating voltage: 5–24V DC.
• Output current: Up to 100mA.
• Power consumption: Less than 20mA.
• Response time: 0.5 milliseconds.
• Wiring: 4-wire connection.
• Protection: Includes built-in protection against reverse polarity and short circuits.
• Ingress protection: Rated IP65, providing protection against dust and low-pressure water jets.
• Housing material: PBT and PC plastic.

Primary applications

The FC-SPX307PZ is suitable for industrial automation tasks that require accurate, non-contact detection within a specific gap. Potential applications include:

• Assembly lines: Detecting the position and counting of small parts.
• Packaging equipment: Monitoring the presence of products or packaging materials.
• Textile machinery: Checking for the presence or absence of threads.
• Manufacturing: Used for automated counting and limit protection.
