FD-V30 Panasonic sensor

Name: FD-V30 Panasonic sensor
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

FD-V30 Panasonic sensor
Sensing Mode: Diffuse-reflective type.
Sensing Range (STD mode): Up to 65 mm when used with an FX-500 series amplifier. This range varies depending on the amplifier and settings (e.g., up to 240 mm in HYPR mode).
Fiber Type: Sleeve type, side-view beam direction.
Fiber Head Diameter: 3 mm.
Cable Length: 2 meters, free-cuttable.
Allowable Bending Radius: R2 mm, due to its high-flex cable design.
Environmental Resistance: IP30 rated protection; operating temperature range of -55 to +80°C.
Housing Material: Stainless steel head.
