FE6070C FLEXEM HMI

FE6070C FLEXEM HMI
Key Technical Specifications

• Display: 7-inch 16:9 TFT LCD with a resolution of 800x480 pixels.
• Touch Panel: 4-wire industrial-grade resistive touchscreen.
• Performance: Equipped with a 600MHz ARM Cortex-A8 CPU and 128MB Flash + 128MB DDR3 memory.
• Connectivity: Includes USB Host 2.0 and USB Slave 2.0 ports for programming, and serial ports supporting RS232, RS485, and RS422 protocols.
• Power: Operates on a standard DC 24V input with a typical power consumption of less than 10W.
• Protection: Features an IP65-rated front panel, making it resistant to dust and water ingress in harsh industrial environments.
