FFB0412VHN DC Brushless Cooling Fan

FFB0412VHN DC Brushless Cooling Fan

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

FFB0412VHN DC Brushless Cooling Fan
Key Specifications

Dimensions: 40mm x 40mm x 28mm
Rated Voltage: 12 VDC (operating range typically 4.5V to 13.2V)
Air Flow: 15.79 CFM (0.447 m³/min)
Speed: 9500 RPM
Noise Level: 45.0 dB(A)
Power Consumption: ~1.92 Watts (0.16A–0.24A depending on the exact sub-model)
Bearing Type: Dual Ball Bearing
Operating Temperature: -10°C to +70°C

Common Applications
Precision cooling in
CNC machinery and industrial automation controllers
Power supply units (PSUs) and telecommunication gear

If you'd like, let me know:
  • What device or project you are installing this fan into

I can provide more tailored installation or purchasing advice
View full details
