FRC-320-I riko sensor
Core Technical Overview
- Coaxial Multi-Core Design: Features a structured fiber arrangement, typically placing an emitter core in the center surrounded by receiver cores to ensure uniform, multidirectional light reflection and minimize blind spots.
- Threaded Bolt Style: Built with standard M3 metric threading (\(M3 \times P0.5\)) for straightforward, secure mounting through machine panels and brackets.
- Robust Material Housing: Encased in high-durability SUS303 stainless steel to withstand harsh industrial wear and tear. [
Specifications at a Glance
According to the official the hardware configuration is detailed below:
- Thread Size: M3 standard thread (\(0.5\text{ mm}\) pitch)
- Housing Material: SUS 303 Stainless Steel
- Total Sleeve Length: \(23\text{ mm}\)
- Tip Diameter: \(\varnothing 1.25\text{ mm}\)
- Fiber Core Layout: Central \(\varnothing 0.5\text{ mm}\) single-core emitter
- Outer Sheath Diameter: \(\varnothing 2.2\text{ mm}\) [1]
