Keyence FS-V11 Fiber Amplifier Sensor

Keyence Fiber Amplifier FS-V11 Digital Fiber Optic Sensor Amplifier Cable Type, Main Unit, NPN, Red LED, 250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER TURBO) Response time, LIGHT-ON/DARK-ON (switch-selectable), NPN open-collector 100 mA max. (24 VDC max.), Residual voltage: 1 V max Control output, Reversed polarity protection, over-current protection, surge absorber, Up to 16 expansion units can be connected (a total of 17 units), 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Power voltage, 50 mA or less Current consumption, -10 to +55 °C 35 to 85 % RH Ambient temperature, The sensor includes selectable timer functions: ON-delay (40 ms), OFF-delay (10 ms), and timer OFF mode.

Specification/Additional Details

• Voltage12 to 24 VDC +-10 %, Ripple (P-P) 10 % or less
• BrandKeyence
• TypeOptical Fiber Amplifier
• Light SourceRed LED
• InterfaceMutual interference suppression capabilities
• Interface : Mutual interference suppression capabilities

• Model Number : FS-V11

• Switching Output : NPN
• Response time : 0.25 ms (FINE) / 0.5 ms (TURBO) / 1 ms (SUPER TURBO)

• Operation mode : LIGHT-ON/DARK-ON (switch-selectable)

• Display indicator : Red LED

• Digital LED monitor : Seven segments, four digits, red LED

• Bar LED monitor : One orange LED and six green LEDs

• Timer function : ON-delay: 40 ms /OFF-delay: 10 ms /Timer OFF (switch-selectable)

• Control output : NPN open-collector 100 mA max. (24 VDC max.), Residual voltage: 1 V max.

• Protection circuit : Reversed polarity protection, over-current protection, surge absorber

• Unit expansion : Up to 16 expansion units can be connected (a total of 17 units)

• Mutual interference suppression : FINE : 4, TURBO/SUPER: 8

• Current consumption : 50 mA or less

• Ambient light : Incandescent lamp: 10,000 lux max., Sunlight: 20,000 lux max.

• Ambient temperature : -10 to +55  DegreeC 14 to 131  DegreeF (No freezing)

• Relative humidity : 35 to 85 % RH (No condensation)

• Case material : Polycarbonate
