Keyence Digital Fiber Optic Sensor Amplifier FS-V33P

Keyence FS-V33P Fiber Amplifier, Cable Type, Main Unit, PNP, Keyence FS-V33P Digital Fiber Optic Sensor, Amplifier

The Keyence FS-V33P Digital Fiber Optic Sensor Amplifier is a high-performance main unit with two PNP outputs and one external input. It is part of the FS-V30 series and is known for its high speed, stability, and dual digital display.

Specifications

• Model type: FS-V33P (2-output + 1-input with cable)
• Output type: PNP, open-collector, two outputs
• Power supply: 12 to 24 VDC ±10%, with a ripple (P-P) of 10% or less
• Control output: 100 mA max. total current for the two outputs in a main unit configuration
• Light source: Red, 4-element LED (wavelength: 640 nm)
• Response time: Selectable from six different settings, including 33 µs (HIGH SPEED) and 16 ms (MEGA TURBO)
• Display: Dual 7-segment digital monitor with a 4-digit green LED for the preset value and a 4-digit red LED for the current value
• Detection modes: Features include light intensity detection, automatic sensitivity-tracking, and limited light intensity detection
• Expansion: Can be connected with up to 16 expansion units (a total of 17 units)
• Dimensions: 30.3 mm (H) x 9.8 mm (W) x 71.8 mm (D)

Key features

The FS-V33P is equipped with several features that allow for easy setup and operation in industrial environments:

• Dual digital display: This feature allows for simultaneous viewing of the current sensing value and the preset reference value, improving visibility and simplifying adjustments.
• Automatic sensitivity-tracking: The unit can automatically adjust its sensitivity to maintain stable detection, even if environmental conditions change.
• Power booster switch: This allows you to quickly switch to a high-power "MEGA" mode with a simple DIP switch operation.
• Multiple timer functions: The amplifier includes several timer options, such as ON-delay, OFF-delay, and one-shot, with durations selectable from 0.1 ms to 9,999 ms.
• Environmental resistance: The unit is built to withstand harsh industrial conditions, with resistance to vibration and shock, as well as a wide operating temperature range.
