FSNA10-N/D f&c sensor

FSNA10-N/D f&c sensor
Key Specifications

• Sensor Type: Ring-shaped inductive proximity sensor
• Ring Inner Diameter: 10 mm
• Output Configuration: NPN output (normally open / switching transducer)
• Operating Voltage: 12–24 VDC (or 10–30 VDC range)
• Sensing Application: Counting small metal parts, screws, or iron/steel objects falling through the ring
• Operating Temperature: -25°C to 70°C
• Protection Degree: IP67 (dust and waterproof)
