FSP400-60GHC (400W) power supply (FSP GROUP)

FSP400-60GHC (400W) power supply (FSP GROUP)
Key Technical Specifications

• Total Power: 400W.
• Form Factor: Standard ATX (PS2) measuring approximately 140 x 150 x 86 mm.
• Efficiency: Typically 80% to 82%.
• Input Voltage: Universal 100–240V AC (full range).
• DC Output Rails:
  • +3.3V: 24.0A.
  • +5V: 23.0A.
  • +12V1: 17.0A.
  • +12V2: 15.0A.
  • -12V: 0.5A.
  • +5Vsb: 2.5A.
• Cooling: Internal 12V DC fan with thermal speed control ("Noise Killer").
• Protection: Includes over-voltage, short-circuit, and over-current protection.
