FTR-H1CA024V FUJITSU relay

FTR-H1CA024V FUJITSU relay
Electrical Specifications

• Coil Voltage: 24V DC
• Coil Resistance: 1,100 Ohms
• Coil Power: 530 mW
• Contact Configuration: SPDT (1 Form C)
• Contact Rating: 10A at 250V AC / 30V DC (resistive load)
• Max Switching Voltage: 400V AC / 300V DC

Physical & Operating Features

• Mounting Style: PCB Mount / Through-Hole (PC Pin)
• Height Profile: Low profile (16.5 mm)
• Operating Temperature: -40°C to +75°C
• Enclosure: Plastic sealed
