FV105-1210CW Infoscan sensor

FV105-1210CW Infoscan sensor
Core Technical Specifications

• Image Sensor: 1280 × 960 pixels (1.2 MP) CMOS sensor.
• Frame Rate: 60 frames per second (fps).
• Decoding Accuracy: Down to 1.6 mil for 1D codes and 2 mil for 2D codes (Data Matrix, QR codes).
• Illumination & Optics: Built-in autofocus optics with integrated illumination (typically featuring combinations of polarized or colored LED light segments to effectively read Direct Part Marking (DPM) barcodes on reflective surfaces).
• Industrial Connectivity: Embedded support for RS232, TCP/IP, Ethernet, Profinet TCP, Modbus TCP, and EtherNet/IP.
• Environmental Protection: Housed in a rugged aluminum alloy casing with an IP65 rating to withstand dusty and wet manufacturing environments.

Key Use Cases & Performance

• High-Speed Reading: Capable of achieving stable decoding at speeds up to 42,000 codes per hour (99.8%+ read rates).
• Target Markets: Extensively deployed in consumer electronics manufacturing, automotive part tracing, logistics sorting, and PCB assembly lines.
• Setup Software: Configured via Infoscan’s Infostepper software utility.
