FX2N-32ER-ES/UL Power module

FX2N-32ER-ES/UL Power module
Key Specifications & Features

• Power Supply Input: 100 V to 240 V AC (allowable range: 85 V to 264 V AC).
• Power Consumption: 35 W.
• Integrated I/O: 32 total points split evenly into 16 Digital Inputs (24V DC Sink/Source) and 16 Relay Outputs (up to 240V AC / 30V DC, 2A per point).
• Service Power Supply: Includes a built-in 24V DC service power output (up to 460 mA) to power sensors or additional connected extension blocks.
• PLC Compatibility: Fully compatible with MELSEC FX1N, FX2N, FX3G, and FX3U series base controllers.
• Safety Certifications: Complying with UL, cUL, and CE standards.
