FX3U-3A-ADP Mistubishi controller

FX3U-3A-ADP Mistubishi controller
Specifications and Features

• Functionality: Provides analog control for small to medium-sized processes, allowing for precise monitoring and control of various parameters like temperature, pressure, or motor speed.
• Channels:
  • Analog Inputs: 2 channels, configurable for either voltage or current input.
  • Analog Outputs: 1 channel, configurable for either voltage or current output.
• Signal Ranges:
  • Voltage: 0 to 10 V DC.
  • Current: 4 to 20 mA.
• Resolution: 12-bit conversion for high accuracy.
• Power Supply: The 5V DC interface power is supplied from the main PLC unit, but the 24V DC conversion circuit drive power supply must be connected externally to the terminal block.
• Compatibility: Designed for use with FX3U series PLCs and also compatible with FX3S, FX3G, FX3GC, and FX3UC series PLCs, potentially requiring an additional adapter like the FX3G-CNV-ADP or an expansion board depending on the specific model.
• Integration: Data is automatically updated in special relays and registers, simplifying programming and commissioning with software like GX Works2 or GX Developer.
• Dimensions: Extremely compact size of 17.6 mm (width) x 90 mm (height) x 89.5 mm (depth).
