FYQM4045A two-phase micro-stepping stepper motor driver

FYQM4045A two-phase micro-stepping stepper motor driver
Core Specifications

• Input Voltage: DC 24V to 40V
• Output Current: Adjustable from 0.6A to 4.5A
• Compatible Motors: 2-phase 28mm, 42mm (NEMA 17), and 57mm (NEMA 23) series
• Micro-stepping: Features multi-mode phase excitation (e.g., 1-2, W1-2, 2W1-2, 4W1-2) to reduce vibration and noise
• Protections: Overheat, overcurrent, and short-circuit protection

Common ApplicationsThe driver is primarily used for precise, fractional millimeter movement. It is widely applied in:

• 3D Printers
• Laser Cutting / Engraving
• Labeling and Pick-and-Place Machines
• X-Y-Z Linear Tables
