QYSMT

G-100A MOTOR Cooling Fan

Name: G-100A MOTOR Cooling Fan
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

G-100A MOTOR Cooling Fan
Type: Axial flow fan.
Voltage: Typically 380V AC (three-phase), with 220V AC variants available.
Power: Ranges from 52W to 95W depending on specific variant and manufacturer.
Frequency: 50 Hz.
Speed: Approximately 2800 RPM.
Air Flow (Capacity): Varies, but around 650 to 660 m³/h is common.
Paddle Diameter: The bare fan blade diameter is around 186mm to 193mm.
Material: Often constructed with a metal or carbon steel body and blades.
Protection Class: IP54 (for some specific models like the "Force Cooling Fan for Motors G100A").
Insulation Class: F.
