G-90A MOTOR Cooling Fan

G-90A MOTOR Cooling Fan
SpecificationsThe G-90A fan is designed for industrial applications and is a forced ventilation unit for 90-frame motors.

• Voltage: Typically AC 380V (three-phase), though 415V and 230V options may be available depending on the manufacturer.
• Power: 42 W.
• Speed: 2800 RPM (revolutions per minute).
• Air Flow: 500 m³/h.
• Noise Level: 55 dBA.
• Dimensions: Approximately 175mm in diameter.
• Material: Features high-hardness carbon steel fan blades and typically a metal frame for durability.
• Protection Class: Rated at IP54 or IP55, offering protection against dust and water ingress.
• Design: It utilizes an outer rotor structure motor with the fan blades fastened to the rotor, which offers a compact design and large airflow.

Online RetailersYou can purchase the G-90A motor cooling fan from several online merchants. The table below lists a few options with general pricing information.
