G2RV-1-S-G 21VDC OMRON RELAY

G2RV-1-S-G 21VDC OMRON RELAY
Core Technical SpecificationsAccording to official product documentation from Omron Industrial Automation, this miniature electromagnetic relay adheres to the following specifications:

• Contact Configuration: SPDT (1 Form C)
• Coil Voltage: 21V DC
• Max Switching Current: 6 A
• Rated Switching Voltage: 250V AC / 30V DC
• Max Switching Voltage: 440V AC / 125V DC
• Coil Power Consumption: Approximately 300 mW
• Contact Material: Silver (Ag) Alloy
• Terminal Type: Plug-in / PC pin (with robust pins designed to prevent bending during replacement)
• Features: Transparent casing for easy visual inspection, built-in coil surge absorption circuit, and non-latching operation.
