G3PE-215B DC-12-24 omron relay

G3PE-215B DC-12-24 omron relay
Key SpecificationsAccording to data from Omron Industrial Automation and DigiKey, the technical parameters include:

• Load Current: 15 A (maximum at ).
• Rated Load Voltage: 100 to 240 V AC (Load voltage range: 75 to 264 V AC).
• Control Voltage: 12 to 24 V DC (Operating range: 9.6 to 30 V DC).
• Switching Mode: Zero Crossing, which minimizes electrical noise by turning on at the zero point of the AC cycle.
• Circuit Configuration: SPST-NO (1 Form A).
• Isolation: Photo triac coupler with 2,500 V dielectric strength.
• Physical: Slim 22.5 mm width; weight approximately 240 g.
