G3R-ODX02SN DC output Solid State Relay (SSR)

 G3R-ODX02SN DC output Solid State Relay (SSR)
Key Technical Specifications

• Input / Supply Voltage: 5 to 24 VDC operating range.
• Rated Load Voltage: 4 to 60 VDC (suitable for 5 to 48 VDC nominal systems).
• Maximum Load Current: 2 A continuous.
• Switching Type: Random Turn-On.
• Dielectric Strength: 4,000 VAC for 1 minute between input and output pins.
• Built-in Indicator: Features an integrated Red LED to visibly monitor active operation status.
• Mounting Method: Plugs directly into standard matching relay sockets such as the for easy 35 mm DIN rail tracking.

Typical Applications

• PLC Interface Systems: Buffering delicate PLC outputs to drive heavy DC field solenoids, valves, or actuators.
• Sensor Interfacing: Managing high-speed signal transitions from specialized industrial proximity or photoelectric sensors.
• Industrial Automation: Control panels, consumer electronics machinery, and automated manufacturing lines.
