G46-10-02 PRESSURE GUAGE SMC

G46-10-02 PRESSURE GUAGE SMC
Technical SpecificationsAccording to official product documentation from SMC and listings on MISUMI,
the gauge has the following key specifications:

• Pressure Range: Maximum indicated pressure of 1.0 MPa (approximately 10 bar or 150 psi).
• Connection Size: R 1/4 (taper pipe thread).
• Outer Diameter: Approximately 42mm (some sources list 42.5mm).
• Accuracy: Indication precision of ±3% F.S. (Full Span).
• Construction: Features a brass Bourdon tube and a clear cover made of polycarbonate.
• Mounting: Back-side thread (rear entry) designed for direct installation into regulators or panels.
