Omron G6D-F4B DC 24V General Purpose Relay
Omron General Purpose Relay G6D-F4B 24VDC Coil Four-point Terminal Relay, SPST-NO (1 Form A) x 4, 8.3 mA Coil Current, 5 A Contact (Current) Rating, 250VAC 30VDC Max. Switching Voltage, DIN Rail.
The G6D-F4B is commonly used in industrial control cabinets as an interface for automation systems like Programmable Logic Controllers (PLCs). It provides a bridge between low-power control signals and higher-power loads, enabling the control of devices
Features:
- Independent coils and contacts for each of the four relay points.
- An LED indicator for each relay shows the operational status.
- A built-in diode absorbs coil surge.
- A protective terminal cover is included to prevent electric shocks.
- Dimensions: 31 mm (W) × 35 mm (H) × 68 mm (D).
- Cross-compatible replacement: The individual G6D relays used in the terminal can be replaced with model G6D-1A-ASI.
