Omron G7SA-5A1B-DC24 Safety Relay

Omron G7SA-5A1B DC24 Safety Relay Plug-in 5PST-NO SPST-NC 6 A Forcible-guided Contacts Configurable

Specification/Additional Details

• Number Of Poles : 4-6 Pole
• Material : Plastic
• Model Name/Number : G7SA-5A1B-DC24
• Coil Voltage : 24VDC
• Current : 6A
• Relay Type : Safety Relay
• Supply Voltage : 24V DC

• Contact Form : 6PST-5NO/1NC (5 Form A, 1 Form B)

• Switching Voltage : 250V AC, 125V DC - Max

• Termination Style : PC Pin, Plug In

• Operate Time : 20ms

• Release Time : 10ms

• Coil Current : 20.8mA

• Coil Power : 500mW

• Coil Resistance : 1.15 kOhms
