G9SX-GS226-T15-RC MAke omron

G9SX-GS226-T15-RC MAke omron
Product SpecificationsAccording to Omron and various vendor sites, the key specifications of the Omron G9SX-GS226-T15-RC DC24 unit are:

• Function: Safety guard switching unit with two operation modes (auto/manual switching).
• Safety Category: Certified for PL e/Category 4 (EN ISO 13849-1) and SIL3 (IEC/EN 61508).
• Rated Supply Voltage: 24 VDC.
• Outputs:
  • Instantaneous Safety Outputs: 2 P-channel MOS-FET outputs (max. 0.8 A DC/output).
  • OFF-delayed Safety Outputs: 2 P-channel MOS-FET outputs (max. 0.8 A DC/output).
  • Auxiliary Outputs: 6 PNP transistor outputs (for monitoring, max. 100 mA DC/output).
• Off-Delay Time: Selectable in 16 steps, from 0 to 15 seconds (e.g., 0, 0.2, 0.3, ... 15 s).
• Terminals: Spring-cage terminals (indicated by the "RC" in the model number).
• Mounting: DIN rail mountable.
• Diagnostics: Features clear LED indicators for easy diagnosis of all inputs and outputs.
