GDS-3011W OETAI Sensor

GDS-3011W OETAI Sensor
Technical Specifications

• Light Source: White light (coaxial reflection type)
• Sensing Distance: 10 mm (±2 mm)
• Switching Output: NPN, NO+NC configuration with dual bright-pass/dark-pass toggle conversion
• Response Time: Under 1 ms
• Operating Voltage: DC 12V to 30V (±10%)
• Output Current: ≥80 mA
• Dimensions: Approx. 90 x 45 x 22 mm
• Weight: ~150g

Key Features

• Fast Detection: Rapid response time under 1 ms handles high-speed automated production lines.
• Dual Output & Protection: Includes short-circuit protection, reverse power protection, and bright/dark pass selection.
• Industrial Application: Designed to accurately detect registration color marks on packaging films and moving webs.
