INGUN GKS 003 206 254 A3000 Spring-loaded Test Probe (test needle)

INGUN Probe GKS-003 206 254 A 3000 Test Pin, GKS-003 206 254 A 3000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-003 206 254 A3000, GKS-003 206 254 A3000 33.1mm Long Circuit Test Needle

The GKS 003 206 254 A3000 is a specific model of spring-loaded test probe (test needle) manufactured by INGUN. It is designed for use in in-circuit tests (ICT) and function tests (FCT) in applications with limited space.

Technical Specifications

• Manufacturer: INGUN
• Series: GKS-003
• Total Length: 33.1 mm
• Barrel Diameter: 2.03 mm
• Working Stroke: 4.4 mm
• Maximum Stroke: 6.35 mm
• Spring Force at Working Stroke: 3 N
• Current Rating: 5 A
• Max. Contact Resistance: < 20 mΩ
• Tip Diameter: 2.54 mm
• Blade Tip Shape: Serrated
• Contact Material: Steel, gold-plated
• Mounting: Push-in
• Operating Temperature: -40°C to 80°C
• Features: Magnetic, quick-exchange system

Application

This test probe is part of a quick-exchange system and is used for contacting test points such as pads, vias, and pins on printed circuit boards during in-circuit testing (ICT) and function testing (FCT).
