INGUN GKS-050 214 050 A 2000 Spring-loaded Test Probe (test needle)

INGUN Probe GKS-050 214 050 A 2000 Test Pin, GKS-050 214 050 A 2000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-050 214 050 A 2000, GKS-050 214 050 A 2000 43.2 mm Long Circuit Test Needle

The GKS-050 214 050 A 2000 test probe is a standard-stroke, spring-loaded test probe manufactured by INGUN. It is commonly used for in-circuit testing (ICT) and function testing (FCT) of printed circuit boards (PCBs).

Specifications

• Manufacturer: INGUN
• Series: GKS-050
• Total Length: 43.2 mm
• Barrel Diameter: 0.78 mm
• Tip Diameter: 0.5 mm
• Tip Style: 4-point, corona (self-cleaning)
• Spring Force at Working Stroke: 2 N
• Recommended Working Stroke: 4.3 mm
• Maximum Stroke: 6.35 mm
• Current Rating: 2 A
• Max. Contact Resistance: 20 mΩ
• Mounting: Push-in type, compatible with KS-050 receptacles
• Operating Temperature: -40°C to 80°C
• Materials/Plating: Steel contact material, gold-plated finish

This probe is designed for reliable contact to test points such as pads, vias, and pins on PCBs.
