INGUN GKS-075 207 064 A1500 Spring-loaded Test Probe (test needle)

INGUN Probe GKS-075 207 064 A 1500 Test Pin, GKS 075 207 064 A 1500 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-075 207 064 A1500, GKS-075 207 064 A1500 33.1mm Long Circuit Test Needle

The GKS 075 207 064 A1500 is a specific model of spring-loaded test probe manufactured by INGUN. It is used for in-circuit tests (ICT) and function tests (FCT) of printed circuit boards (PCBs).

Key Specifications

• Manufacturer: INGUN
• Series: GKS-075
• Total Length: 33.1 mm
• Barrel Diameter: 1.02 mm
• Tip Diameter: 0.64 mm
• Tip Style: Chisel
• Current Rating: 3 A
• Working Stroke: 4.3 mm
• Maximum Stroke: 6.35 mm
• Spring Force at Working Stroke: 1.5 N
• Spring Pre-load: 0.6 N
• Operating Temperature: -40 to 80°C
• Contact Plating: Gold-plated
• Mounting: Push-in
