INGUN GKS-075 214 064 A 2000 Spring-loaded Test Probe (test needle)

INGUN Probe GKS 075 214 064 A 2000 Test Pin, GKS-075 214 064 A 2000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-075 214 064 A2000, GKS-075 214 064 A 2000 33.1mm Long Circuit Test Needle

The GKS 075 214 064 A 2000 is a specific model of a spring-loaded test probe (test needle) manufactured by INGUN. It is primarily used for in-circuit testing (ICT) and function testing (FCT) of printed circuit boards (PCBs).

Specifications

• Manufacturer: INGUN
• Series: GKS-075
• Application: Used for contacting test points (pads, vias, pins) on PCBs in test fixtures.
• Mounting: Push-in type, compatible with KS-075 series receptacles.
• Tip Style: 4-point crown (self-cleaning)
• Tip Diameter: 0.64 mm
• Material: Steel (contact material), gold-plated (contact plating)
• Total Length: 33.1 mm
• Barrel Diameter: 1.02 mm
• Current Rating: 3 A
• Spring Force (at working stroke): 2 N
• Recommended Working Stroke: 4.3 mm
• Maximum Stroke: 6.35 mm
• Operating Temperature: -40°C to 80°C (standard version)
