INGUN GKS-075 214 100 A 1500 Spring-loaded Test Probe (test needle)

INGUN Probe GKS 075 214 100 A 1500 Test Pin, GKS-075 214 100 A 1500 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-075 214 100 A1500, GKS-075 214 100 A 1500 33.1mm Long Circuit Test Needle

The GKS-075 214 100 A 1500 is a specific model of spring-loaded test probe (test needle) manufactured by INGUN. It is primarily used for in-circuit testing (ICT) and function testing (FCT) of printed circuit boards (PCBs).

Specifications

• Manufacturer: INGUN
• Series: GKS-075
• Total Length: 33.1 mm
• Barrel Diameter: 1.02 mm
• Grid (Pitch): 1.91 mm (75 mil)
• Working Stroke: 4.3 mm
• Maximum Stroke: 6.35 mm
• Spring Force at Working Stroke: 1.5 N
• Current Rating: 3 A
• Tip Style: The number "100" in the part number corresponds to a specific tip style (likely a crown or 4-point style based on similar models).
• Contact Material: Steel (based on similar models in the series)
• Installation: Plug-in type, compatible with KS-075 receptacles.

This probe is designed for reliable and precise contacting of test points such as pads, vias, and pins on electronic assemblies.
