GKS 100 214 050 A 3000 Test Probe
GKS 100 214 050 A 3000 Test Probe
Contact Seller :- Call or Whatsapp +91 93544 02545 vitika@qysmt.in
Contact Seller :- Call or Whatsapp +91 93544 02545 vitika@qysmt.in
Call or Whatsapp
+91 93544 02545
Email: vitika@qysmt.in
INGUN GKS-100 214 050 A 3000 Spring-loaded Test Probe (test needle)
INGUN Probe GKS-100 214 050 A 3000 Test Pin, GKS 100 214 050 A 3000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-100 214 050 A 3000, GKS-100 214 050 A3000 33.4mm Long Circuit Test Needle
The GKS 100 214 050 A 3000 is a spring-loaded test probe (also known as a test needle) manufactured by INGUN. It is primarily used for in-circuit tests (ICT) and function tests (FCT) of printed circuit boards (PCBs).
Specifications
| Manufacturer | INGUN | |
| Product Group | ICT / FCT test probe | |
| Series | GKS-100 | |
| Mounting | Push-in (plug-in type) | |
| Grid / Pitch | 2.54 mm (100 mil) | |
| Total Length | 33.4 mm | |
| Barrel Diameter | 1.37 mm | |
| Working Stroke | 4.3 mm | |
| Maximum Stroke | 6.35 mm | |
| Spring Force (at working stroke) | 3 N | |
| Current Rating | 5 A | |
| Contact Material | Steel | |
| Contact Plating | Gold-plated | |
| Tip Style | 4-point crown, self-cleaning | |
| Tip Diameter | 0.5 mm | |
| Operating Temperature | -40°C to 80°C |
