INGUN GKS-100 214 130 A1000 Spring-loaded Test Probe (test needle)
INGUN Probe GKS-100 214 130 A 1000 Test Pin 4-point Crown Tip, GKS-100 214 130 A 1000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-100 214 130 A1000, GKS 100 214 130 A1000 33.4mm Long Circuit Test Needle
The GKS 100 214 130 A 1000 Test Probe is a specific model of spring-loaded test probe manufactured by INGUN. It is designed for In-Circuit Testing (ICT) and Function Testing (FCT) applications, primarily for contacting printed circuit boards (PCBs).
Key Specifications
| Manufacturer | INGUN |
| Series | GKS-100 |
| Part Number (Item) | GKS-100-0001 |
| Grid (Pitch) | 2.54 mm (100 mil) |
| Current Rating | 5 A |
| Max. Contact Resistance | < 20 mΩ |
| Spring Force at Working Stroke | 1 N |
| Working Stroke | 4.3 mm |
| Max. Stroke | 6.35 mm |
| Total Length | 33.4 mm |
| Barrel Diameter | 1.37 mm |
| Tip Style | 4-point crown, self-cleaning |
| Tip Diameter | 1.3 mm |
| Contact Material | Steel, gold-plated |
| Operating Temperature | -40°C to 80°C |
| Mounting Type | Plug-in (compatible with KS-100 receptacles) |
Features
- Quick-exchange system
- Magnetic
- Suitable for contacting pads, pins, and posts
