INGUN GKS-100 288 150 A 2000 Spring-loaded Test Probe (test needle)
INGUN Probe GKS-100 288 150 A 2000 Test Pin, GKS-100 288 150 A 2000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-100 288 150 A2000, GKS 100 288 150 A2000 33.4mm Long Circuit Test Needle
The GKS 100 288 150 A 2000 Test Probe is a spring-loaded test probe manufactured by INGUN. It is designed for use in In-Circuit Testing (ICT) and Function Testing (FCT) applications, primarily for contacting PCBs, pads, vias, and pins.
Key Specifications
| Manufacturer | INGUN | |
| Series | GKS-100 | |
| Type | Spring-loaded test probe (test needle) | |
| Grid (Pitch) | 2.54 mm (100 mil) | |
| Current Rating | 5A | |
| Working Stroke | 4.3 mm | |
| Maximum Stroke | 6.35 mm | |
| Spring Force (at working stroke) | 2 N | |
| Tip Diameter | 1.5 mm | |
| Tip Style | 8-point (corona) | |
| Contact Material | Steel | |
| Contact Plating | Gold-plated | |
| Total Length | 33.4 mm | |
| Barrel Diameter | 1.37 mm | |
| Mounting | Push-in (requires a receptacle, e.g., KS-100 series) | |
| Operating Temperature | -40°C to 80°C |
