INGUN GKS-100 293 160 A 2000 Spring-loaded Test Probe (test needle)

INGUN Probe GKS 100 293 160 A 2000 Test Pin, GKS-100 293 160 A 2000 INGUN Test Needle, ICT/FCT in-circuit Function Testing Test Needle GKS-100 293 160 A2000, GKS-100 293 160 A 2000 38.4 mm Long Circuit Test Needle

The GKS 100 293 160 A 2000 test probe is a specific model of spring-loaded test needle manufactured by INGUN. It is primarily used for contacting printed circuit boards (PCBs) in in-circuit testing (ICT) and functional testing (FCT) applications.

Specifications

• Manufacturer: INGUN
• Series: GKS-100
• Current Rating: 5 A
• Working Stroke: 4.3 mm
• Maximum Stroke: 6.35 mm
• Spring Force at Working Stroke: 2 N
• Tip Diameter: 1.6 mm
• Tip Style: 3-point, sharp blade tip
• Total Length: 38.4 mm (There is also an "E" variant with a 43.4 mm length)
• Barrel Diameter: 1.37 mm
• Contact Material/Plating: Steel with gold-plated finish
• Mounting: Push-in
• Operating Temperature: -40 to 80°C
• Max. Contact Resistance: 20 mΩ

Applications

• Testing of electronic components and assemblies, such as PCBs, wiring, and plug connectors.
• Used in the manufacture, research and development, quality control, and repair of electronic devices like smartphones, computers, and automotive electronics.
• Enables precise contact to test points such as pads, vias, and pins.
