GM705S Proximity sensor

GM705S Proximity sensor
Technical Specifications

• Sensor Type: Fail-Safe Inductive Sensor
• Electrical Design / Output: DC PNP with 2 x OSSD (Output Signal Switching Device) safety outputs (A1 and A2)
• Operating Voltage: 19.2 to 30 V DC (Current consumption < 30 mA)
• Sensing Range (Enable Zone): 4 to 20 mm (Non-flush mountable)
• Safe Switching-Off Distance \(s(ar)\): 45 mm
• Response Time: Rapid 50 ms response time to safety requests
• Housing Dimensions: 40 x 40 x 66 mm (Rectangular housing)
• Material Composition: Rugged Diecast Zinc and PPE
• Connection Type: 1 x M12 connector with gold-plated contacts (A-coded)
• Ingress Protection: IP 65 and IP 67 (Weatherproof Class C applications)
• Operating Temperature: -25°C to 60°C

Key Benefits & Safety Ratings

• High-Level Certifications: Meticulously certified to international standards including ISO 13849-1 (Category 3, PL e), IEC 61508 (SIL 3), and IEC 62061 (SIL 3).
• No Special Actuator Needed: Operates efficiently on standard metal targets, entirely bypassing the need for specific electronic actuators or target magnets.
• Direct Safety PLC Integration: The dual OSSD PNP outputs hook up directly into existing safety PLCs and safe evaluation units.
• Clear Diagnostics: Built-in dual LED system featuring a green light for power status and a yellow light for the target signal.
• Electrical Safeguards: Fully equipped with reverse polarity and short-circuit protection to secure your hardware investment.
